| Model No. | A | B | C | D | E | F | G | H | I | J | K |
| Inverter- Plus 07/10 | 591 | 836 | 379 | 335 | 98 | 640 | 98 | 107 | 290 | 26 | 11 |
| Inverter- Plus 13/17/21 | 641 | 896 | 389 | 363 | 128 | 640 | 128 | 170 | 340 | 26 | 11 |
| Inverter- Plus 30/35H | 7405 | 1056 | 428 | 401 | 173 | 710 | 173 | 1015 | 440 | 27 | 17 |
Sizes are in mm.
| Parameter | Inverter Plus 7 | Inverter Plus 10 | Inverter Plus 13 | Inverter Plus 17 | Inverter Plus 21 | Inverter Plus 30 | Inverter Plus 35 |
| Heating Capacity at Air 26°C, Humidity 80%, Water 26°C in, 28°C out | |||||||
| Heating Capacity (kW) | 7.81-1.78 | 10.58-2.41 | 13.64-3.11 | 17.21-3.91 | 21.43-4.86 | 30.06-6.84 | 35.81-8.29 |
| Power Input(kW) | 1.13-0.11 | 1.52-0.15 | 1.95-0.19 | 2.47-0.25 | 3.08-0.31 | 4.32-0.43 | 5.13-0.51 |
| COP | 15.72-6.92 | 15.81-6.94 | 16.11-6.98 | 15.94-6.96 | 15.92-6.95 | 16.09-6.96 | 16.11-6.98 |
| Heating Capacity at Air 15°C, Humidity 70%, Water 26°C in, 28°C out | |||||||
| Heating Capacity (kW) | 5.82-1.32 | 7.91-1.80 | 10.16-2.31 | 12.83-2.92 | 15.94-3.62 | 22.02-4.98 | 28.72-6.65 |
| Power Input(kW) | 1.18-0.18 | 1.59-0.24 | 2.04-0.30 | 2.58-0.38 | 3.22-0.48 | 4.43-0.66 | 5.77-0.87 |
| COP | 7.54-4.94 | 7.58-4.96 | 7.63-4.98 | 7.61-4.97 | 7.57-4.95 | 7.59-4.97 | 7.63-4.98 |
| Cooling Capacity at Air 35°C, Water 29°C in, 27°C out | |||||||
| Cooling Capacity (kW) | 4.21-1.11 | 5.86-1.45 | 7.21-1.79 | 9.43-2.31 | 11.52-2.94 | 15.82-3.88 | 20.14-4.72 |
| Power Input(kW) | 1.13-0.17 | 1.57-0.22 | 1.89-0.26 | 2.51-0.34 | 3.16-0.43 | 4.19-0.56 | 5.27-0.68 |
| EER | 6.59-3.71 | 6.71-3.74 | 6.94-3.82 | 6.88-3.76 | 6.85-3.65 | 6.92-3.78 | 6.98-3.82 |
| Power suply | 220-240V / 1/50-60 Hz | ||||||
| Rated Power Input (kW) | 1.2 | 1.6 | 2.1 | 2.6 | 3.2 | 4.4 | 5.7 |
| Rated Current(A) | 5.4 | 7.3 | 9.4 | 11.7 | 14.6 | 20.1 | 26 |
| Compressor | Mitsubishi | ||||||
| Refrigerant | R32 | ||||||
| Heat Exchanger | Titanium | ||||||
| Air Flow Direction | Horizontal | ||||||
| Water Flow Volume(m³/h) | 1.25~3.75 | 1.75~5.25 | 2.25~6.75 | 2.75~8.25 | 3.25~9.75 | 4.5~13.5 | 6~18 |
| Kind of defrost | by 4 way valve | ||||||
| Working temperature range(°C) | -15~43 | ||||||
| Noise level (dBa) at 1m | <36~<45 | <37~<46 | <39~<47 | <40~<48 | <41~<49 | <42~<50 | <42~<50 |
| Noise level (dBa) at 1m | <19~<26 | <20~<26 | <20~<28 | <21~<30 | <23~<31 | <24~<33 | <24~<33 |
| Casing Material | ABS plastic | ||||||
| Net Dimensions(mm) (LxWxH) | 836x379x591 | 896x389x641 | 1056x416x744 | ||||
| Package Dimensions(mm) (LxWxH) | 930x400x716 | 990x435x750 | 1146x460x869 | ||||
| Net Weight(kg) | 42 | 43 | 53 | 54 | 58 | 86 | 90 |
| Gross Weight(kg) | 51 | 53 | 64 | 65 | 69 | 97 | 101 |
| Water Proof Level | IPX4 | ||||||
Sizes are in mm.
